Premium 10-Input 2-Bus Mixer with XENYX Preamps, British EQs and Optional Battery Operation

XENYX 1002B
Got a solo gig at the local coffee shop? Need to make a quick public announcement? Simple sound calls for the simply superb XENYX 1002B, the BEHRINGER mixer with everything you need to give an intimate setting incredible sound. The ultra-compact XENYX 1002B mixer’s 10 Inputs (2 mic channels, 4 stereo channels with 3 extra mic inputs) allow you to effortlessly achieve premium-quality sound, thanks to the 2 studio-grade, phantom-powered XENYX Mic Preamps and ultra-musical 3-band “British” channel EQ. The XENYX 1002B’s compact size and flexible input scheme make it the natural choice of sports announcers for calling play-by-play game action. Likewise, radio and TV reporters especially like the XENYX 1002B for its ease-of-use, remarkable fidelity and rugged reliability. And the 1002B’s convenient 9 V battery capability allows newscasters and correspondents to use the 1002B in remote locations – where the nearest power outlet may be many miles away!

Sonically Superior Mic Preamps
The XENYX 1002B gets its name from our legendary, high headroom XENYX mic preamps, which have been praised by audio engineers all over the world. These state-of-the-art mic pres represent a major step in the evolution of audio technology – and they can easily hold their own, even when compared to the most expensive stand-alone mic preamps. XENYX preamps off er a staggering 130 dB of dynamic range, with a bandwidth that extends from below 10 Hz to well above 200 kHz. Armed with these outstanding mic preamps, the XENYX 1002B provides such transparent, crystal-clear performance you just might think someone upgraded your mics while you weren’t looking.

Sublimely Musical British EQ
The British consoles of the 1960s and ‘70s changed the sound of rock and roll – without them the British Invasion might not have happened. Those legendary mixing desks soon became the envy of engineers and producers all over the world. The channel EQ on our XENYX mixers is based on that very same circuitry, allowing you to imbue signals with incredible warmth and detailed musical character. Even when applied generously, these equalizers exhibit sweet forgiveness and superb audio quality.

Mono Inputs
Microphone Inputs (XENYX Mic Preamp)
Type: XLR connector, electronically balanced, discrete input circuit
Mic E.I.N.1 (20 Hz - 20 kHz)
 @ 0 Ω source resistance: -134 dB 135.7 dB A-weighted
@ 50 Ω source resistance: -131 dB 133.3 dB A-weighted
@ 150 Ω source resistance: -129 dB 130.5 dB A-weighted
Frequency response (-1 dB)
<10 Hz - 160 kHz (-1 dB)
Frequency response (-3 dB)
<10 Hz - 200 kHz (-3 dB)
Gain range
+14 dB to +60 dB
Max. input level
+12 dBu @ +10 dB GAIN
Impedance
2.6 k Ohms balanced
Signal-to-noise ratio
120 dB A-weighted (0 dBu In @ +22 dB GAIN)
Distortion (THD + N)
0.005% / 0.004% A-weighted
Line Input
Type
¼" TRS jack, electronically balanced
Impedance
20 k Ohms balanced, 10 k Ohms unbalanced
Gain range
-10 dB to +40 dB
Max. input level
+22 dBu @ 0 dB GAIN
Frequency Response (Mic In → Main Out)
<10 Hz - 90 kHz (-1 dB)
+0 dB / -1 dB
<10 Hz - 160 kHz (-3 dB)
+0 dB / -3 dB
Stereo Inputs
Type
2 x ¼" TRS jack, balanced
Impedance
20 k Ohms balanced, 10 k Ohms unbalanced
Gain range
-20 dB to +20 dB
Max. input level
+22 dBu @ 0 dB GAIN
CD/Tape In
Type
RCA connector
Impedance
10 k Ohms
Max. input level
+22 dBu
Equalizer
LOW
50 Hz / ±15 dB
MID
700 Hz / ±15 dB
HIGH
10 kHz / ±15 dB
Channel Inserts
Type
¼" TRS jack, unbalanced
Max. input level
+22 dBu
MON/FX Send
Type
¼" mono jack, unbalanced
Impedance
120 Ohms
Max. output level
+22 dBu
Main Outputs
Type
¼" TRS jack, electronically balanced
Impedance
240 Ohms balanced, 120 Ohms unbalanced
Max. output level
+28 dBu
Phones Output
Type
¼" TRS jack, unbalanced
Max. output level
+19 dBu / 150 Ohms (+25 dBm)
CD/Tape Out
Type
RCA connector
Impedance
1 k Ohms
Max. output level
+22 dBu
Main Mix System Data (Noise)
Main mix @ -∞, channel fader @ -∞
-100 dB / -102.5 dB A weighted
Main mix @ 0 dB, channel fader @ -∞
-82 dB / -85 dB A weighted
Main mix @ 0 dB, channel fader @ 0 dB
-72 dB / -75 dB A weighted
Power Supply
Power consumption
50 W
Fuse (100-120 V~, 50/60 Hz)
T 2,0 A H 250 V
Fuse (220-230 V~, 50/60 Hz)
T 2,0 A H 250 V
Mains Connector
USA/Canada: 120 V~, 60 Hz, Power Supply MXUL4
U.K./Australia: 240 V~, 50 Hz, Power Supply MXUK4
China/Korea: 220 V~, 50 Hz, Power Supply MXCHN4
Europe: 230 V~, 50 Hz, Power Supply MXEU4
Japan: 100 V~, 50-60 Hz, Power Supply MXJP4
Phantom Power
With battery power
+18 V
With AC adaptor
+23 V
Battery
Battery life
4 hours w/ high quality Alkaline battery
Physical/Weight
Dimensions (H x W x D)
1 9/16" / 2 7/8 x 11 3/4 x 8 1/2"
40 mm / 73 x 298 x 216 mm
